D4.800
AMAZING POWER TO SIZE RATIO
£299.00
Availability: 1 in stock
Related products
-
Sale!
The D4.800 also has conformal coated internal components and sealed back switches making it perfect for motorcycle, boat, and powersport applications. As if this amp didn’t have enough going for it, DD also has a line of made for Harley Davidson Brackets that allow the D4.800 to cleanly and securely mount into 2014 and up Harley Road Glides and Street Glides.
Features
Bandpass Crossovers
Clipping Indicators
Input Mode
Auto Turn On
Set Screw Power Connections
Set Screw Speaker Connections
Differential RCA Inputs
Discrete Outputs
Specifications
| Frequency Response (Hz) | 30 – 30k |
| Operating Voltage | 9 – 16 |
| Test Voltage | 14.4 |
| Output Channel | 4 |
| Total Wattage | 800 |
| Continuous Wattage @ 4Ω | 125 x 4 / 400 x 2 |
| Continuous Wattage @ 2Ω | 200 x 4 |
| Max Current Draw | 80 |
| RCA Input Voltage Sensitivity | 8 – 0.2 |
| RCA Input S/N | > 90dB |
| Damping Factor | > 100 |
| THD | < 0.2% |
| Sub-Sonic Filter | 30 – 5k |
| Low-Pass Filter | 50 – 5k |
| Power Wire Gauge In | 4 |
| Speaker Wire Gauge Out | 16 |
| Dimensions (In) | 7 x 4 x 1.7 |
| Dimensions (MM) | 180 x 104 x 43 |
